| Item | 25G SFP28 Transceiver |
| Part No. | LS-SM3125-02C |
| Part Status | Active |
| Form Factor | SFP28 |
| Max Data Rate | 25Gbps |
| Wavelength | 1310nm |
| Max Cable Distance | 2km |
| Media | SMF |
| Connector | Duplex LC |
| Optical Component | DFB/PIN |
| TX Power | -7~2.5dBm |
| Receiver Sensitivity | <-12dBm |
| Receiver Overload | 2dBm |
| Power Consumption | 1.2W |
| DDM/DOM | Supported |
| Commercial Temperature Range | 0℃ to 70°C / -40℃ to 85℃ |
| Protocols | SFP28 MSA, SFF-8472 |
| Warranty | 5 Years |
| Sample | Available |
We draw on over 10 years of experience in chips and modules to integrate fast speeds, small size, power savings, and high performance in every module.
A full series of optical modules is provided for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
End-to-end DWDM configurations are available with an extensive selection of optical elements—ranging from high-performance active modules to passive devices. This comprehensive solution features optical amplifiers (EDFA & RFA), Mux & Demux modules, OPM, ROADM, MCS, OLP, and OTDR systems to support robust network deployments.
To address the intense demands of high-capacity data transmission within modern data centers, we offer a complete suite of high-speed optical modules. Supporting speeds ranging from 10G up to 800G, these components deliver exceptional reliability and efficiency for cloud and enterprise infrastructures.
Built with reliable laser modules and mainstream chipset designs, our wireless networking solutions are built for optimal transmission stability. Supporting Dark Fiber, WDM, Radio over Fiber, and high-speed mid-haul/back-haul infrastructure, these modules are optimized to handle diverse 4G/5G deployment scenarios.
Tailored for telecommunication operators and network builders, our comprehensive FTTx solutions cover the entire spectrum of fiber-to-the-x applications. We provide all-optical and combined copper-fiber interfaces engineered to streamline deployment costs while maintaining peak access speeds.
To secure consistent network uptime, we supply specialized optical line operations and maintenance equipment. This includes Optical Line Protection (OLP) systems and comprehensive Optical Line Monitoring (OLM) systems designed to rapidly detect and mitigate fiber signal loss.
We are a specialized manufacturer of magnetic telecom and networking components, certified under ISO9001:2000, RoHS, REACH, CE, and UL standards. Our operations utilize advanced manufacturing machinery and precise test equipment to ensure compliance with strict international guidelines.
Operating with a robust production scale and abundant capacity, we are fully equipped to deliver high-quality components within reduced lead times.
Additionally, we supply a complete lineup of optical modules designed for fixed networks, wireless base stations, carrier networks, and high-performance cloud data centers, serving a global clientele with reliable optoelectronic designs.
