Product Description

Low-Profile RJ-45 Connector Group
Low-Profile RJ-45 Connector L840-1JX1-43 L837-1X1T-43 L8AD-1E1T-BF L834-1X1T-43
Products Description
Item RJ45 Female Connector
Part Number L840-1JX1-43 L837-1X1T-43 L8AD-1E1T-BF L834-1X1T-43
Part Status Active
Connector Type Jack
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Application-Lan Ethernet (Non-PoE)
Number of Ports 1x1 Port
Speed 10/100 Base-T
Latch Up
Cores per Port 8
Orientation 90° Angle (Right)
PCB Mount Angle SIDE ENTRY
Shield EMI Tabs With
LED Option Green/Yellow
PCB FR4
PCB Retaining Post T POST
Temperature 0°C TO 70°C
Bst Circuit Yes
AutomDX YES
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Turns Ratio RX/TX 1CT:1CT
Configuration RX/TX T,C
RJ45 Connector Side View
RJ45 Connector Bottom View
Ethernet Connector Dimension Diagram 1
Ethernet Connector Dimension Diagram 2
Ethernet Connector Electrical Schematic 1
Ethernet Connector Electrical Schematic 2
RJ45 Connector Product Lineup
Technical Specifications and Standards
Product Quality Certification 1
Product Quality Certification 2
Product Quality Certification 3
Factory Production Line 1
Factory Production Line 2
Quality Testing Lab
Company Profile
Established in 1997, our company is a professional designer and manufacturer of magnetic telecom and networking components, offering an extensive line of state-of-the-art catalog products as well as custom capabilities.
We are a global supplier of magnetic telecom and networking components to OEMs, contract manufacturers, and CEMs, serving more than 10,000+ customers across 200 countries. By building multi-warehouse systems in key areas and continuously increasing inventory, we are committed to becoming the world's leading Ethernet RJ45 connector and LAN transformer supplier.
Corporate Office Building
Modern Warehouse Logistics
FAQ
Are you a factory or a trading company?
We are a specialized manufacturer of magnetic telecom and networking components, including RJ45 connectors, LAN transformers, RJ11 connectors, and SFP modules.
Can I get a sample before mass production?
Yes, we can offer you free samples to test quality, but shipping costs are to be covered by the client.
What is your delivery time?
Items in stock are ready to ship immediately, while mass production orders typically require 15-30 days.
What after-sales service do you offer?
We provide a one-year warranty period along with 24-hour online technical support.
Can you accept OEM/ODM orders?
Yes, please send your requirements to us so we can proceed with a detailed discussion.
What is your key advantage?
We possess over 19 years of manufacturing experience and have maintained long-term partnerships with major global companies like Intel and Jabil.
