Tab Up Shield 1 Port RJ 45 Jack 5G Base-t Low Profile Female RJ45 Connector
Tab Up Shield 1 Port RJ 45 Jack 5G Base-t Low Profile Female RJ45 Connector
Tab Up Shield 1 Port RJ 45 Jack 5G Base-t Low Profile Female RJ45 Connector
Tab Up Shield 1 Port RJ 45 Jack 5G Base-t Low Profile Female RJ45 Connector
Tab Up Shield 1 Port RJ 45 Jack 5G Base-t Low Profile Female RJ45 Connector
1 / 5
Tab Up Shield 1 Port RJ 45 Jack 5G Base-t Low Profile Female RJ45 Connector
Tab Up Shield 1 Port RJ 45 Jack 5G Base-t Low Profile Female RJ45 Connector
Tab Up Shield 1 Port RJ 45 Jack 5G Base-t Low Profile Female RJ45 Connector
Tab Up Shield 1 Port RJ 45 Jack 5G Base-t Low Profile Female RJ45 Connector
Tab Up Shield 1 Port RJ 45 Jack 5G Base-t Low Profile Female RJ45 Connector

Tab Up Shield 1 Port RJ 45 Jack 5G Base-t Low Profile Female RJ45 Connector

Send Inquiry

Product Description

Tab Up Shield 1 Port RJ 45 Jack 5G Base-t Low Profile Female RJ45 Connector
RJ45 Female Connector Lan Transformer SFP Cage SFP Modules
Products Description
Item RJ45 Female Connector
Part Number LPJM7501AHNL
Part Status Active
Connector Type Jack
Number of Positions/Contacts 10p8c (RJ45, Ethernet)
Application-Lan Ethernet(NoN PoE)
Number of Ports 1x1 Port
Speed 5G Base-T
Latch Up
Cores per Port 4
Orientation 90° Angle (Right)
PCB Mount Angle SIDE ENTRY
Shield EMI Tabs With
LED Option Green/Yellow
PCB FR4
PCB Retaining Post T POST
Temperature -40°C TO 85°C
Bst Circuit Yes
AutomDX YES
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Turns Ratio RX/TX 1CT:1CT
Configuration RX/TX T,C
