10/100/1000 Base-T RJ45 Stacked Jack 2x6 port RJ45 Jack RJGE-12M6170DJP
Part Number
RJGE-12M6170DJP
Application-LAN
ETHERNET(NON POE)
AutomDX
YES
Bst Circuit
YES
Configuration RX
T,C
Configuration TX
T,C
Contact Mating Area Plating
GOLD 6u"/15u"/30u"
Cores Per Port
4
Diodes
NO DIODES
LED Option
WITH/WITHOUT LEDS
Latch
UP/DOWN
Number of Ports
2X6
PCB
FR4
PCB Mount Angle
SIDE ENTRY
PCB Retaining Post
T POST
Pin Type
THT SOLDER
RoHS Compliant
YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search
YES
Shield EMI Tabs
WITH OR WITHOUT
Speed
10/100/1000/10G BASE-T
Temperature
0 TO 70°C/-40 TO 85°C
Turns Ratio RX
1CT:1
Turns Ratio TX
1CT:1
Why Choose Us
World’s Leader Supplier Of Integrated RJ45 Connector And Discrete Magnetic Transformers
Professional Certification
ISO 9001:2008
UL Certification
Reach Certification
RoHS Compliance
Active Environmental Policy
100% Guarantee Quality
Manufactured Under Strict Controls.
100% Tested (Not Just Batch Tested)
OEM Of TE (Tyco) For 9 Years
Successful Customer: Texas Instruments Samsung Cisco Siemens And Intel…
Preferred Supplier Of TI (Texas Instruments)
Quality Guarantee: 6 Years
Competitive Price & Service
More Competitive Price Than Pulse Tyco Halo Wurth And Amphenol
Delivery Time: 2-3 Weeks After Orders
Free Samples Are Available
Provide New Design For Customer Requirements
90% Off Shipping Cost By DHL UPS FEDEX Or TNT
Corporate Policy
The Corporate Goal Is To Achieve The Highest Level Of Customer Satisfaction Through Continuous Improvements In Quality, Delivery And Service
Committed To And Expects Quality Performance From Every Employee
The Company Standard Is Defect-Free Products And Services
Preferred Supplier Of TI Samsung Cisco Siemens …
You Will Look At The Logo On BeagleBone Board
10/100/1000 Base-T RJ45 Stacked Jack 2x6 port RJ45 Jack RJGE-12M6170DJP
Frequently Asked Questions
What is the maximum speed supported by this stacked RJ45 jack?
This connector supports speeds of 10/100/1000 Base-T, as well as configurations up to 10G Base-T, making it ideal for high-speed Gigabit Ethernet applications.
Does this connector support Power over Ethernet (PoE)?
No, this specific part number is designed for non-PoE Ethernet applications.
What are the options available for LED configurations and EMI shielding?
This connector can be supplied with or without integrated LEDs and has multiple options for EMI tabs to match your board layout requirements.
What temperature range can this stacked jack operate in?
It is designed to perform in standard commercial temperature ranges from 0 to 70°C, and industrial-grade temperature environments from -40 to 85°C.
What plating thicknesses are available on the contact mating area?
We offer standard Gold plating thicknesses of 6u", 15u", or 30u" to ensure excellent signal reliability and oxidation resistance based on your environmental requirements.
