100GBASE-DR Single Lambda QSFP28 100G 1310nm 500m Duplex LC SMF Optical Transceiver Module
100GBASE-DR Single Lambda QSFP28 100G 1310nm 500m Duplex LC SMF Optical Transceiver Module
100GBASE-DR Single Lambda QSFP28 100G 1310nm 500m Duplex LC SMF Optical Transceiver Module
100GBASE-DR Single Lambda QSFP28 100G 1310nm 500m Duplex LC SMF Optical Transceiver Module
100GBASE-DR Single Lambda QSFP28 100G 1310nm 500m Duplex LC SMF Optical Transceiver Module
1 / 5
100GBASE-DR Single Lambda QSFP28 100G 1310nm 500m Duplex LC SMF Optical Transceiver Module
100GBASE-DR Single Lambda QSFP28 100G 1310nm 500m Duplex LC SMF Optical Transceiver Module
100GBASE-DR Single Lambda QSFP28 100G 1310nm 500m Duplex LC SMF Optical Transceiver Module
100GBASE-DR Single Lambda QSFP28 100G 1310nm 500m Duplex LC SMF Optical Transceiver Module
100GBASE-DR Single Lambda QSFP28 100G 1310nm 500m Duplex LC SMF Optical Transceiver Module

100GBASE-DR Single Lambda QSFP28 100G 1310nm 500m Duplex LC SMF Optical Transceiver Module

Send Inquiry

Product Description

100GBASE-DR Single Lambda QSFP28 100G 1310nm 500m Duplex LC SMF Optical Transceiver Module
Part No. LQ-SM31100-DR1C
Form Factor QSFP28
Max Data Rate 100Gbps
Wavelength 1310nm
Max Cable Distance 500m
Connector Duplex LC
Media SMF
Transmitter Type EML
Receiver Type PIN
EMC (Electro Magnetic Compatibility) Supported
DDM/DOM Supported
Protocols IEEE 802.3cd 100GBASE-DR Specification compliant
Temperature Range 0 to 70°C / -40 to 85°C
Warranty 5 Years
Sample Available
View Our Solutions
We draw on over 10 years of experience in chips and modules to integrate fast speeds, small size, power savings, and high performance in every module.
We provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
100GBASE-DR Single Lambda QSFP28 Transceiver Module Specification
High Performance Optical Design Features
100G QSFP28 Internal Architecture
Global Network Service and Support Quality
High Speed Transceiver Compatibility Options
Core Solutions
Optical Transport Networks Solution
Optical Transport Networks
We can provide end-to-end DWDM device with almost all optical devices - from active modules to optical passive devices, including optical amplifier(EDFA & RFA), Mux & Demux, OPM, ROADM, MCS, OLP and OTDR etc.
Cloud and Enterprise Data Centers
Cloud and Enterprise
To meet the demand of mass data transmission in data centers, we have developed a series of high-speed optical module which the product rate ranging from 10G to 800G, providing high-quality optical interconnection solutions for data centers.
4G 5G Wireless Backhaul Networks
Wireless
We provide high reliability and performance products with mature and efficient lasers and mainstream chip solutions to our customers all around the world. The solution includes Dark Fiber, WDM, Radio over Fiber, High Speed, Mid-haul and Back-haul which could meet all the needs of various scenarios in 4G/5G systems.
FTTx Optical Fiber Access Networks
FTTx
Aim to global communication network constructers, we provide FTTx optical fiber access total solutions covered from all-optical or optical copper combined access solutions and products.
Subsystems Optical Line Protection
Subsystems
To ensure the normal operation of the communication line, we provide the optical cable O&M solution which integrates an optical line protection system (OLP) and an optical line monitoring system (OLM).
Related Products SFP Cage
Metal SFP Shielding Cage Connector
Why Choose Us
Quality Manufacturing Control Process
Advanced Testing Instruments for Modules
Automated Clean Room Assembly Line
Strict Compliance Standard Certificates
Company Profile
We are a specialized manufacturer of magnetic telecom and network components, certified by ISO9001:2000, ROSH, REACH, CE and UL, with advanced manufacturing equipment and testing equipment imported from abroad. Our company was established in 1997, we have about 2000 employees at present. With the abundant production capacity of 3000K per month, we are able to deliver products within the short time.
In addition, we can provide a complete series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks. The range also includes high-speed optical interconnect solutions for cloud computing and ultra-broadband networks. Using the latest optoelectronic technologies, we design, manufacture and sell products worldwide.
High Tech Production Workshop View
Precision Laser Testing Equipment
Frequently Asked Questions
1. Are you a factory or a trading company?
We are a specialized manufacturer of magnetic telecom and networking components, such as RJ45 connectors, LAN transformers, RJ11 connectors, and SFP modules, etc.
2. Can I get a sample before mass production?
Yes, we can offer you free samples to test quality, but you are responsible for the shipping fee.
3. What is your delivery time?
Ready to ship for stock items and 15-30 days for mass production orders.
4. What after-service can you offer?
One year guarantee period and we can offer technical support online 24 hours.
5. Can you accept OEM/ODM orders?
Yes, please send an inquiry to us so that we can have a detailed discussion.
6. What is your advantage?
19 years of production experience and we have partnered with leading global enterprises for many years.
