Lumetra
Lumetra
| Item | Fiber Optical Modules |
| Part Status | Active |
| Form Factor | QSFP-DD |
| Max Data Rate | 400Gbps |
| Max Cable Distance | 70m@OM3/100m@OM4 |
| Wavelength | 850nm |
| Connector | MTP/MPO-16 (APC) |
| Media | MMF |
| Optical Component | VCSEL/PIN |
| TX Power | -6~4dBm |
| RX Power | -7.9~4dBm |
| Modulation | 8x 50G PAM4 |
| Powerbudget | 1.9dB |
| Power Consumption | ≤10W |
| Extinction Ratio | 3dB |
| DDM/DOM | DDM Supported |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
| Warranty | 5 Years |
| Sample | Available |
| Protocols | IEEE 802.3cd, QSFP-DD MSA, CMIS 4.0 |
We draw on over 10 years of experience in chips and modules to integrate fast speeds, small size, power savings, and high performance in every module. We provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
We are a specialized manufacturer of magnetic telecom and networking components, such as RJ45 connectors, LAN transformers, RJ11 connectors, and SFP modules.
Yes, we can offer you free samples to test quality, with the shipping fee covered by the buyer.
Items in stock are ready to ship immediately, while mass production typically takes 15-30 days.
We provide a one-year guarantee period along with 24-hour online technical support.
Yes, please send an inquiry to us so we can discuss the details of your project.
We possess 19 years of dedicated production experience in the communications components industry.
