| Item | Value |
|---|---|
| Part Number | LPJG68837A63NL |
| Cross Part Number | JG0-0070NL |
| Part Status | Active |
| Connector Type | RJ45 |
| Applications-Lan | Ethernet(Non_PoE) |
| Speed | 10/100/1000 Base-T, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Contact Finish Thickness | 6.00µin (0.152µm) |
| LED Color | Green/Green&Orange Led |
| Number of Cores per Jack | 8 |
| Shielding | Shielded, Emi Finger |
| Number of Ports | 1x6 Port |
| Features | Board Guide |
| Tab Direction | Up |
| Contact Finish | Gold |
| Configuration RX/TX | T,C |
| Turns Ratio RX/TX | 1CT:1CT |
| Operating Temperature | 0°C ~ 70°C |
We are a specialized manufacturer of magnetic telecom and networking components, certified by ISO9001:2000, ROHS, REACH, CE, and UL. Our facilities own advanced manufacturing equipment and testing instruments imported from abroad. With abundant production capacity of 3000K per month, we are able to deliver goods within a short lead time. Moreover, we provide professional complete solutions for magnetic components alongside strong technical support.
Our products are widely used in networking and communication equipment such as HUBs, PC cards, Switches, Routers, PC Mainboards, SDH, PDH, IP Phones, and xDSL modems.
Main Products:
We are a manufacturer specialized in RJ45 connectors and LAN Transformers for more than 23 years.
Yes, 3-5 pcs of free samples are available for your testing. Small batches are also acceptable.
Yes. We have rich experience and the capability to put your design and ideas into real products, and we can laser print your brand on the products.
We have a highly professional team. Usually, we can ship within 30 days. For specific order details, please reach out to our sales team.
The operating temperature range for this model is 0°C to 70°C, making it suitable for standard commercial applications.
No, this specific model is designed for Non-PoE standard Ethernet applications. Please check the specification sheet for detailed pin configurations.
