Product Description

Shielded Magnetic Dual Ports RJ-45 Connector 1840538-3 6610128-1 1840538-4 1840538-2

Shielded Magnetic Dual Ports RJ-45 Connector 1840538-3 6610128-1 1840538-4 1840538-2

Shielded Magnetic Dual Ports RJ-45 Connector 1840538-3 6610128-1 1840538-4 1840538-2
Shielded Magnetic Dual Ports RJ-45 Connector 1840538-3 6610128-1 1840538-4 1840538-2
Shielded Magnetic Dual Ports RJ-45 Connector 1840538-3 6610128-1 1840538-4 1840538-2
Part Number 1840538-3 6610128-1 1840538-4 1840538-2
Application-LAN ETHERNET(NoN POE)
AutomDX YES
Bst Circuit YES
Configuration RX T,C
Configuration TX T,C
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Cores Per Port 6
Diodes NO DIODES
LED Option GREEN/GREEN
Latch UP
Number of Ports 1x2
PCB FR4
PCB Mount Angle SIDE ENTRY
PCB Retaining Post T POST
Pin Type THT SOLDER
RoHS Compliant YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search YES
Shield EMI Tabs WITH
Shielding Shielded
Speed 10/100 Base-T
Temperature 0 ~ 70℃
Turns Ratio RX 1CT:1
Turns Ratio TX 1CT:1
Shielded Magnetic Dual Ports RJ-45 Connector Dimension Drawing
• Preferred Supplier Of TI Samsung Cisco Siemens ...
Shielded Magnetic Dual Ports RJ-45 Connector Internal Layout
Shielded Magnetic Dual Ports RJ-45 Connector Features
Shielded Magnetic Dual Ports RJ-45 Connector Specs

Why Choose Us

Supplier Of Integrated RJ45 Connector And Discrete Magnetic Transformers

Professional Certification
  • ISO 9001:2008
  • UL Certification
  • Reach Certification
  • RoHS Compliance
  • Active Environmental Policy
100% Quality Guarantee
  • Manufactured Under Strict Controls
  • 100% Tested (Not Just Batch Tested)
  • OEM For TE (Tyco) For 9 Years
  • Successful Customers: Texas Instruments, Samsung, Cisco, Siemens, Intel...
  • Preferred Supplier Of TI (Texas Instruments)
  • Quality Guarantee: 6 Years
Competitive Price & Service
  • More Competitive Price Than Pulse, Tyco, Halo, Wurth, and Amphenol
  • Delivery Time: 2-3 Weeks After Orders
  • Free Samples Are Available
  • Provide New Design For Customer Requirements
  • 90% Off Shipping Cost By DHL, UPS, FEDEX, or TNT
Shielded EMI Finger Cat4 Cat5e 8p8c RJ45 Connector
Shielded Magnetic Dual Ports RJ-45 Connector Structural Design
Shielded Magnetic Dual Ports RJ-45 Connector Dimension Details

Shielded Magnetic Dual Ports RJ-45 Connector 1840538-3 6610128-1 1840538-4 1840538-2

Frequently Asked Questions

What is the speed rating of this RJ-45 connector?
This connector supports 10/100 Base-T network transmission speeds.
Is this RJ-45 connector PoE (Power over Ethernet) compatible?
No, this model is designed for ETHERNET (Non-PoE) applications.
What is the operating temperature range?
The standard operating temperature range for this connector is 0℃ to 70℃.
Does the connector comply with RoHS standards?
Yes, it is RoHS compliant, specifically meeting RoHS-5 standards with a lead-in-solder exemption.
What certifications do these connectors hold?
The products are manufactured under strict controls and carry ISO 9001:2008, UL Certification, and Reach Certification.
Can I request free samples for testing?
Yes, free samples are available upon request, with standard delivery times of 2-3 weeks after placing the request.
